BIODIESEL HOSE, FKM rubber, DIN 73379 type B
BIODIESEL HOSE, HNBR rubber
Resistance against biodiesel, petrol and diesel fuel,
ECO-DIESEL (RME- and PME -fuel) and all fuel types.
OPTION 1 : BIODIESEL HOSE, FKM rubber, DIN 73379 type B
Inner Tube: Synthetic FKM(Fluor Rubber=VITON), black, smooth
Cover: High tensile textile Braiding, gray
Operating temperature: from -30º C to +220º C
OPTION 2 : BIODIESEL HOSE, HNBR rubber
Inner Tube:Synthetic HNBR(Hydrogenated Nitrile Butadiene Rubber),black,smooth
Cover: High tensile textile Braiding, gray, with orange line
Operating temperature: from -40º C to +160º C
MARKING:
N- DIN 73379 type B IDXOD FKM/CO
OPTION 1: |
OPTION 2: |
ID Ø |
ID Ø |
OD Ø |
Wall |
Bend Radius |
Working |
Bursting |
ARTICLE |
ARTICLE |
|
|
|
Thickness |
|
Pressure |
Pressure |
NUMBER: |
NUMBER: |
[mm]: |
[inch]: |
[mm]: |
[mm]: |
[mm]: |
[Psi/Bar]: |
[Bar]: |
B7-032070 |
B6-032070 |
3,2 |
1/8" |
7 |
1,9 |
26 |
145psi10bar |
435psi30bar |
B7-035075 |
B6-035075 |
3,5 |
1/8" |
7,5 |
2 |
26 |
145psi10bar |
435psi30bar |
B7-040080 |
B6-040080 |
4 |
5/32" |
8 |
2 |
32 |
145psi10bar |
435psi30bar |
B7-045095 |
B6-045095 |
4,5 |
3/16" |
9,5 |
2,5 |
34 |
145psi10bar |
435psi30bar |
B7-050100 |
B6-050100 |
5 |
3/16" |
10 |
2,5 |
40 |
145psi10bar |
435psi30bar |
B7-055105 |
B6-055105 |
5,5 |
7/32" |
10,5 |
2,5 |
42 |
145psi10bar |
435psi30bar |
B7-060110 |
B6-060110 |
6 |
1/4" |
11 |
2,5 |
48 |
145psi10bar |
435psi30bar |
B7-070120 |
B6-070120 |
7 |
9/32" |
12 |
2,5 |
56 |
145psi10bar |
435psi30bar |
B7-075125 |
B6-075125 |
7,5 |
19/64" |
12,5 |
2,5 |
58 |
145psi10bar |
435psi30bar |
B7-080130 |
B6-080130 |
8 |
5/16" |
13 |
2,5 |
65 |
145psi10bar |
435psi30bar |
B7-090140 |
B6-090140 |
9 |
23/64" |
14 |
2,5 |
72 |
145psi10bar |
435psi30bar |
B7-100150 |
B6-100150 |
10 |
3/8" |
15 |
2,5 |
80 |
145psi10bar |
435psi30bar |
B7-110170 |
B6-110170 |
11 |
7/16" |
17 |
3 |
88 |
145psi10bar |
435psi30bar |
B7-120180 |
B6-120180 |
12 |
1/2" |
18 |
3 |
96 |
145psi10bar |
435psi30bar |
*** It is possible to produce diameters according to customer request.
